CS SEAMLESS PIPE

Name: CS SEAMLESS PIPE
Brand: JINDAT STEEL UDYOG PRIVATE LIMITED
Price: 65.0 INR
Availability: InStock

Price 65.0 INR/ Kilograms

Get a Price/Quote

MOQ : 1000 Kilograms

CS SEAMLESS PIPE Specification

Tensile Strength
Yield Strength (YS) 240 MPa (35,000 psi) min Tensile Strength (UTS) 415 MPa (60,000 psi) min Megapascals (MPa )

Material Composition %
Element Composition (%) Carbon (C) 0.30 max Manganese (Mn) 0.29 1.06 Phosphorus (P) 0.035 max Sulfur (S) 0.035 max Silicon (Si) 0.10 min Copper (Cu) 0.40 max*

Steel Type
Carbon Steel

Grade
ASTM A106 Gr B

Thickness
8 Millimeter (mm)

Application
Construction

Dimension (L*W*H)
8 Inch (in)

Weight
250 Kilograms (kg)

Color
BLACK JAPAN COLOUR

Material Grade
ASTM A106 Gr B

Finish Type
PRIME FINISH

CS SEAMLESS PIPE Trade Information

Minimum Order Quantity
1000 Kilograms

Delivery Time
1 Days

CS SEAMLESS PIPE About

CS Seamless Pipe (Carbon Steel Seamless Pipe)

Standards / grades:

ASTM A106 (Gr B / Gr C) high-temp service
ASTM A53 Gr B general piping
API 5L Gr B / X42X70 pipeline service
ASTM A333 low-temperature service

sizes:

OD: to 36 (larger sizes exist)
Schedule: SCH 10, 20, 40, 80, XS, XXS

CS Seamless Pipe (Carbon Steel Seamless Pipe) is a type of pipe manufactured from carbon steel without any welded joint or seam. It is produced by piercing a solid steel billet and then hot rolling or cold drawing it into a hollow cylindrical shape. Because there is no weld, the pipe has uniform strength, higher pressure resistance, and better reliability compared to welded pipes.

These pipes are widely used in high-pressure and high-temperature applications, such as oil and gas transportation, boilers, heat exchangers, power plants, refineries, petrochemical industries, and structural systems. CS seamless pipes offer excellent mechanical strength, durability, and resistance to stress and corrosion (with proper material grade and treatment).

CS Seamless Pipe (ASTM A106 Gr B)

Element	Composition (%)
Carbon (C)	0.30 max
Manganese (Mn)	0.29 1.06
Phosphorus (P)	0.035 max
Sulfur (S)	0.035 max
Silicon (Si)	0.10 min
Copper (Cu)	0.40 max*
Nickel (Ni)	0.40 max*
Chromium (Cr)	0.40 max*
Molybdenum (Mo)	0.15 max*

Engineered for Structural Excellence

CS Seamless Pipes manufactured as per ASTM A106 Gr B standards deliver unmatched strength and integrity for construction requirements. The seamless structure eliminates the risk of weak joints, allowing for superior performance under pressure and load. Their chemical composition and prime finish ensure longevity and resistance to environmental factors, making them a preferred choice in infrastructure projects.

Precise Material and Finish for Demanding Applications

The pipes incorporate a meticulously balanced content of carbon, manganese, and silicon, plus strict limits on phosphorus and sulfur to enhance durability. The black Japan color with a prime finish not only adds to corrosion resistance but also offers an aesthetically sleek look. These features collectively ensure the pipes meet stringent project specifications.

FAQ's of CS SEAMLESS PIPE:

Q: How is the CS Seamless Pipe manufactured with respect to ASTM A106 Gr B standards?

A: The CS Seamless Pipe is manufactured using ASTM A106 Gr B specifications, which involve hot-rolling processes and precise chemical control. The absence of welds in the seamless manufacturing method enhances the pipe's strength and relieves concerns over weak joints found in welded alternatives.

Q: What are the primary benefits of using this seamless carbon steel pipe in construction?

A: The primary benefits include high yield (240 MPa) and tensile strength (415 MPa), robustness under heavy loads, reliable chemical composition, and enhanced safety due to the seamless design. The prime finish and black Japan color improve both durability and resistance to environmental degradation.

Q: Where are these seamless pipes primarily used?

A: These pipes find application mainly in construction projects, including infrastructure, high-rise buildings, industrial facilities, and other areas requiring sturdy and durable piping systems. Their strength also makes them suitable for use in pipelines carrying high-pressure fluids and gases.

Q: When should a project opt for seamless carbon steel pipes over welded ones?

A: Seamless pipes are preferred when the application demands high strength, integrity under pressure, and resistance to potential leaks. They are especially recommended for critical structural projects and fluid transport pipelines where safety and durability are paramount.

Q: What is the process involved in ensuring the pipe's material composition meets international standards?

A: The pipe undergoes strict quality control procedures, including spectrographic analysis and mechanical testing, to ensure compliance with ASTM A106 Gr B material composition standards. This ensures optimal levels of carbon, manganese, silicon, and limited impurities for consistent performance.

Q: How does the prime finish and black Japan color enhance the pipe's performance?

A: The prime finish along with the black Japan color coating increases the pipe's resistance to corrosion, rust, and environmental wear. This protective layer extends the pipe's lifespan even in challenging outdoor or industrial conditions.
